Key Features
• 7" touch screen (HTD 25000 - 30000), 4.3" touch screen (HTD 10000 - 20000)
• Standard MODBUS RS485 communication
• High strength aluminium heat exchanger
• High efficiency scroll (HTD 10000 - 20000) and screw (25000 - 30000) refrigerant gas compressor
• Constant dew point thanks to thermal mass technology
• Stainless steel thermal mass-cooler evaporator and thermal mass circulation pump
• Speed controlled (EC) fan motor
• Zero-loss evacuation
• 10 barg maximum operating pressure
• Water cooled condenser
What is turbo type air dryer?
The new compact design of turbo dryers, which can dry compressed air at high capacities, gathers all the components of the drying system under a single canopy. With HTD Series, compressed air with capacities of 10000 Nm³/h - 30000 Nm³/h can be dried up to 3°C dew point.
In addition, thanks to thermal mass technology, it dries the air with low energy consumption even in systems where compressed air consumption is not constant.
